M92 Popular Scope Voltage Digital Multimeter Tester
voltage digital multimeter
With large screen,
Simple and easy
Accord with the design of CATI
With double fuse, safe and reliable
| Model | M92A | M92B | M92D | M92V |
| Overload protection | √ | √ | √ | √ |
| Low battery indication | √ | √ | √ | √ |
| Diode test | √ | √ | √ | √ |
| Transistor test | √ | √ | × | × |
| Data hold | × | √ | √ | × |
| Continuity buzzer test | √ | √ | √ | √ |
| DCV | 200m-2-20-200-600V ±0.5% | 200m-2-20-200-600V ±0.5% | 200m-2-20-200-600V ±0.5% | 200m-2-20-200-600V ±0.5% |
| ACV | 2-20-200-600V ±1.0% | 2-20-200-600V ±1.0% | 2-20-200-600V ±1.0% | 2-20-200-600V ±1.0% |
| ACA | 200u-2m-20m-200m-10A ±1.8% | 2m-20m-200m-10A ±1.8% | 2m-20m-200m-10A ±1.8% | 2m-20m-200m-10A ±1.8% |
| DCA | 2m-20m-200m-10A ±2.0% | 2m-20m-200m-10A ±2.0% | 2m-20m-200m-10A ±2.0% | 2m-20m-200m-10A ±2.0% |
| OHM | 200-2K-20K-200K-2M-20MΩ ±1.0% | 200-2K-20K-200K-2M-20MΩ ±1.0% | 200-2K-20K -200K-2M-20MΩ ±1.0% | 200-2K-20K-200K-2M-20MΩ ±1.0% |
| Max display | 1999 | |||
| LCD size | 63x27mm | |||
| Product size | 166×85×32mm | |||
| Product Weight | 309g | |||
| Power supply | one 9V 6F22 battery | |||
